OTJ497 49″ 4K LED-edge

Brief Description:

◼Curved Shape, J design, Unique and interative motivation
◼No hot spot, dark spot, dark corner, high level uniformity
◼Rear fire LEDs, glow style
◼4K resolution
◼PCAP powered by General Touch, quality assurance
◼Plastic back cover, light and cost saving
◼Well sealed non LED light leakage
◼Closed frame, compatible with various application


Product Detail

Product Tags

Name

49 Inch LED-Framed Curved Touchmonitor (J-type)

Model

OTJ497

LCD Panel Parameters

Display Technology

Active Matrix TFT-LCD With LED Backlight

Aspect Ratio

16 : 9

Active Area (W x H)

1073.78 × 604.00 mm

Native Resolution

3840 × 2160 @ 60 Hz

Response Time (Typ.)

8 ms

Display Colors

1.07 B

Luminance (Typ.)

500 nits; with PCAP 415 nits

Contrast Ratio (Typ.)

1100 : 1

Viewing Angle (Typ.)

Horizontal (left/right) CR≥10 89°/89°

Vertical (up/down)  CR≥10 89°/89°

Touch Screen Parameters

Touch Technology

Projected Capacitive (PCAP)

Surface Treatment

Tempered or Chemically Strengthened

-

Thickness(Total)

4.5 ± 0.5 mm

Light Transmission

≥83%

Response Time(Typ.)

10 ms

Touch Screen Interface

USB

Touch Point

10

Overall Parameters

Case/Bezel Color

Black

Radius

Panel Frame R1500  (Cover Glass R1493.4)

Mounting Options

VESA: 600 × 400 mm

Outline DimensionsW×H×D

692.0mm × 1150.0mm × 170.8mm, curvature radius 1493.4mm

Power Supply

Monitor: Input Voltage Range: +24VDC ± 5%RGB LED Lights: +5VDC ± 5% Optional LED controller(External): +5VDC ± 5%

On Screen Display (OSD)

Control (back): Power, Auto, Up, Down, Menu

Power Consumption(Max)

130W ( Monitor without RGB LED Lights) 40W (RGB LED Lights)

Operating Altitude

≤3000 m

Temperature Range

Operating: 0to 40, storage: -20to 60

Humidity (Non Condensing)

Operating: 20% to 80%, storage: 10% to 90%

I/O

HDMI, DVI, DP, USB (Type B)

Accessories

Optional

Carton Box Dimensions (1 unit in one carton)

1269 mm (L) × 306 mm (W) × 850 mm (H)

Weight

Net: 27.6 Kg Gross: 34.5 Kg

MTBF

50,000 hours demonstrated

LED Lights Color

Multicolor

LED Lights Location

4 LED lights bar (Front, Edge)

LED Controller (External)

Optional

System Support

Windows 7 or later, Linux 4.4 or later

Agency Approvals

CE, FCC

Warranty

1 Year



Ordering Information

Part Name

Part Number

Description

OTJ497-RC5000-UD5450-2.0

 10202020021R

49” “J type”, UHD, 16:9, 500nits, PCAP, USB, HDMI/DVI/DP, LED lights, front, edge & back



Drawings and Spec Sheet
Spec Sheet Download
